Gradeability |
58 % |
Superstructure turning speed |
10 1/min |
Travel speed |
3 mph / 4.8 km/h |
Break Out Force Bucket |
18.7 kN |
Break Out Force Lift Arm |
9.1 kN |
Length |
141.1" / 3585 mm |
Operating weight (min.-max.) |
3800 - 4592 lb / 1724 - 2083 kg |
Digging depth (max.) |
97.9" / 2486 mm |
Width |
39" / 990 mm |
Height |
92.9" / 2360 mm |
Cylinder |
3 |
Cylinder capacity |
71.8 cu in / 1176 cc |
Tank capacity |
5.8 gal US / 22 l |
Effective power |
18.5 hp / 13.8 kW |
Nominal Engine speed |
2,200 1/min |
Operating power |
18 hp / 13.4 kW |
Operating Engine speed |
2,200 1/min |
Starter battery Voltage |
12 V |
Battery capacity (nom. value) |
44 Ah |
Engine type |
Diesel engine |
Manufacturer |
Yanmar |
Engine designation |
3TNV76 |
Operating pressure |
3,480 psi / 240 bar |
Flow rate |
10.3 gal/min /39 l/min |
Flow rate max. |
10.3 gal/min /39 l/min |
Tank capacity |
5.5 gal US / 21 l |
Operating pressure slewing gear |
150 bar |
Hydraulikpump |
Variable displacement pump |
Operating pressure |
3,480 psi / 240 bar |
Shipping weight |
35186 lb / 1596 kg |
Height with cab |
93.0 inches / 2362 mm |
Total height with rotating beacon |
99.9 inches / 2538 mm |
Width of upper carriage |
39.0 inches / 990 mm |
Width of cab |
34.8 inches / 885 mm |
Width travel gear |
51.2 inches / 1300 mm |
Width travel gear retracted |
39.0 inches / 990 mm |
Width of dozer blade |
51.2 inches / 1300 mm |
Transport length |
111.3 inches / 2828 mm |
Transport length short shovel arm |
141.1 inches / 3584 mm |
Transport length long shovel arm |
139.8 inches / 3551 mm |
Digging depth max., short shovel arm |
91.6 inches / 2326 mm |
Digging depth max., long shovel arm |
97.9 inches / 2486 mm |
Piercing depth max., short shovel arm |
67.4 inches / 1713 mm |
Piercing depth max., long shovel arm |
73.3 inches / 1863 mm |
Piercing height max., short shovel arm |
136.3 inches / 3462 mm |
Piercing height max., long shovel arm |
140.8 inches / 3576 mm |
Dumping height max., short shovel arm |
95.9 inches / 2436 mm |
Dumping height max., long shovel arm |
100.4 inches / 2550 mm |
Digging radius max., short shovel arm |
153.5 inches / 3899 mm |
Digging radius max., long shovel arm |
159.4 inches / 4050 mm |
Max. reach at ground level (short shovel arm) |
151.5 inches / 3848 mm |
Max. reach at ground level (long shovel arm) |
157.6 inches / 4002 mm |
Tail swing radius |
26.0 inches / 660 mm |
Boom offset max. (to center of bucket right side) |
21.0 inches / 533 mm |
Boom offset max. (to center of bucket left side) |
16.5 inches / 418 mm |
Stacking height max. (dozer blade above surface) |
10.7 inches / 271 mm |
Digging depth max. (dozer blade below surface) |
15.4 inches / 390 mm |
Length travel drive |
63.3 inches / 1607 mm |
Max. swivel angle (arm system to the left) |
65 ° |
Max. swivel angle (arm system to the right) |
57 ° |
Track width |
9.1 inches / 230 mm |
Boom swing radius center |
64.1 inches / 1627 mm |
Boom swing radius right |
59.8 inches / 1519 mm |
Boom swing radius left |
54.0 inches / 1372 mm |
Distance bucket dozer blade, short shovel arm |
13.1 inches / 332 mm |
Distance bucket dozer blade, long shovel arm |
10.2 inches / 260 mm |
